Product Description:
DC Brushless Motor is a permanent magnet brushless DC electric motor that is lightweight and high speed. Featuring a weight of 1.2kg and a speed of 3000rpm, this brushless DC motor can perform reliably and efficiently in harsh environments. Additionally, its protection level is IP54 and its insulation class is Class B, making it suitable for use in a wide range of temperatures from -20℃ to +60℃. DC Brushless Motor is ideal for applications that require a reliable and high performance motor.
Features:
- Product Name: DC Brushless Motor
- Shaft Diameter: 6mm
- Noise Level: 50dB
- Power: 100W
- Efficiency: 85%
- Shaft Length: 20mm
- Motor Type: Permanent Magnet Brushless DC Motor
- Motor Design: Brushless DC Electric Motor
Technical Parameters:
| Property |
Value |
| Insulation Class |
Class B |
| Speed |
3000rpm |
| Weight |
1.2kg |
| Power |
100W |
| Voltage |
24V |
| Shaft Diameter |
6mm |
| Protection Level |
IP54 |
| Lifetime |
10000h |
| Motor Type |
DC Brushless |
| Torque |
1.2Nm |
Applications:
DC Brushless Motor is a powerful and reliable choice for a wide range of applications, from industrial to consumer electronics. The motor features a permanent magnet brushless DC motor with a 20mm shaft length, 24V voltage, and an operating temperature range of -20℃ to +60℃. With an IP54 protection level, the motor is designed to be dustproof and splashproof, making it ideal for use in a variety of environments. The motor is also designed to be highly durable and reliable, making it an excellent choice for industrial applications, such as pumps, compressors, and other high-intensity tasks. In addition, the permanent magnet brushless DC motor is also widely used in consumer electronics, such as power tools, toys, and even drones.
Customization:
DC Brushless Motor
Our DC Brushless Motor offers a lifetime of up to 10,000 hours, a maximum torque of 1.2Nm, insulation class B, shaft length of 20mm and operating temperature from -20℃ to +60℃. It is a permanent magnet brushless DC motor with excellent performance.
FAQ:
- Q1: What is the maximum speed of the DC Brushless Motor?
A1: The maximum speed of the DC Brushless Motor is 3,000 RPM.
- Q2: What type of voltage does the DC Brushless Motor use?
A2: The DC Brushless Motor uses a voltage of 24V DC.
- Q3: What is the power rating of the DC Brushless Motor?
A3: The power rating of the DC Brushless Motor is 500W.
- Q4: What is the size of the DC Brushless Motor?
A4: The size of the DC Brushless Motor is 42mm x42mm.
- Q5: What kind of encoder does the DC Brushless Motor use?
A5: The DC Brushless Motor uses a Hall Effect encoder.
